Material: polyamide (PA6)
Temperature range:-40 ℃ ~+120 short time 150 ℃
Features: good elasticity, glossy surface, high mechanical strength, wind resistant, wear-resistant, resistant to oils, acids, solvents, UV-resistant, insulated, free of halogen, phosphor and cadmium.
Protection class: IP68
Color: black, grey Application: machine tool, machine building, electric insulation protection system, electric automatic control systems, transport equipment, automobile manufacturing, Metro, electric locomotive and air-conditioner equipment, etc.
|
名稱 |
規格 |
內徑 (mm) |
外徑 (mm) |
靜態彎曲半徑 (mm) |
動態彎曲半徑(mm) |
包裝長度 （米/卷） |
|
PA軟管 |
7（1/4） |
6.5 |
10.0 |
15 |
30 |
200 |
|
PA軟管 |
10(5/16) |
10.0 |
13.0 |
20 |
40 |
100 |
|
PA軟管 |
12(3/8) |
12.0 |
15.8 |
30 |
50 |
100 |
|
PA軟管 |
16(1/2) |
16.0 |
21.2 |
40 |
70 |
100 |
|
PA軟管 |
22(3/4) |
22.0 |
28.5 |
50 |
100 |
100 |
|
PA軟管 |
28(1) |
28.0 |
34.5 |
60 |
120 |
50 |
|
PA軟管 |
36(1-1/4) |
36.0 |
42.5 |
80 |
150 |
25 |
|
PA軟管 |
48(2) |
46.5 |
54.5 |
100 |
180 |
25 |
|
PA軟管 |
18.5 |
14.3 |
18.5 |
35 |
60 |
100 |
|
PA軟管 |
25 |
20.0 |
25 |
45 |
80 |
100 |
|
PA軟管 |
32 |
26.0 |
31 |
55 |
100 |
50 |
|
型號 |
規格 |
內徑(mm) |
外徑 (mm) |
靜態彎曲半徑(mm) |
動態彎曲半徑(mm) |
包裝 (米/卷) |
|
PP |
1/4 |
6.5 |
10.0 |
15 |
30 |
200 |
|
PP |
5/16 |
10.0 |
13.0 |
20 |
40 |
100 |
|
PP |
3/8 |
12.0 |
15.8 |
30 |
50 |
100 |
|
PP |
1/2 |
16.0 |
21.2 |
40 |
70 |
100 |
|
PP |
3/4 |
22.0 |
28.5 |
50 |
100 |
100 |
|
PP |
1 |
28.0 |
34.5 |
60 |
120 |
50 |
|
PP |
1-1/4 |
36.0 |
42.5 |
80 |
150 |
25 |
|
PP |
2 |
46.5 |
54.5 |
100 |
180 |
25 |
|
PP |
18.5 |
14.3 |
18.5 |
35 |
60 |
100 |
|
PP |
25 |
20.0 |
25 |
45 |
80 |
100 |
|
PP |
32 |
26.0 |
31 |
55 |
100 |
50 |
